MICROTEST 5265 Series Transformer Tester
Microtest 5265 Transformer Tester is an automatic transformer testing instrument designed for production testing of transformers, inductors, and other magnetic components. It provides comprehensive electrical parameter measurements with high accuracy and fast testing speed, making it suitable for transformer manufacturing, quality control laboratories, and automated production environments.
-
- Test Frequency: 10 Hz – 200 kHz
- Basic Accuracy: ±0.1%
- Test Channels: Up to 20 channels for multi-winding transformer testing
- Measurement Parameters: Turns Ratio (TR), Inductance (L), Leakage Inductance (LK), DC Resistance (DCR), Capacitance (C), Impedance (Z), Phase Angle (θ), Quality Factor (Q), Dissipation Factor (D)
- Measurement Modes: Meter Mode and automated multi-step test sequences
- Production Functions: Comparator and BIN sorting for automated classification
- Accuracy Correction: Open / Short correction
- Interfaces: LAN, USB Host, RS-232, Handler
- Automation: Compatible with PLC systems and automated transformer production testing
Microtest 6360 Series Bench Precision LCR Meter (10Hz–1MHz)
Microtest 6360 Series LCR Meter is a precision LCR meter designed for fundamental impedance measurement in component testing, incoming inspection, and automated production environments. It supports test frequencies from DC and 10 Hz up to 20 kHz / 100 kHz / 200 kHz / 500 kHz / 1 MHz (model dependent), delivering reliable measurements for capacitors, inductors, resistors, and related passive components.
-
- Test Frequency: DC, 10 Hz – 20 kHz / 100 kHz / 200 kHz / 500 kHz / 1 MHz (model dependent)
- Basic Accuracy: Up to ±0.05%
- Display: Up to 4 parameters simultaneously
- Measurement Parameters: |Z| (Impedance), |Y| (Admittance), θ (Phase Angle), X (Reactance), R (Series / Parallel Resistance), G (Conductance), B (Susceptance), L (Inductance), C (Capacitance), D (Dissipation Factor), Q (Quality Factor), DCR (DC Resistance)
- Production Functions: Comparator and automated sorting functions (model/configuration dependent)
- Accuracy Correction: Open / Short correction
- Interfaces: LAN, USB Host, RS-232, Handler
- Automation: Suitable for PLC integration and automated component testing
MICROTEST 6630 Series High-Frequency LCR Meter
Microtest 6630 Series High Frequency LCR Meter is a precision impedance measurement instrument designed for component characterization, material analysis, and automated production testing. It supports frequencies from 10 Hz up to 50 MHz with high measurement accuracy and fast testing speed, making it suitable for both R&D laboratories and automated production environments.
-
- Frequency Range: 10 Hz – 1 / 3 / 5 / 10 / 20 / 30 / 50 MHz (model dependent)
- Basic Accuracy: ±0.05%
- Measurement Speed: <3 ms
- Output Impedance: Selectable 25 Ω / 100 Ω
- Automatic Level Control: Ensures stable test signals
- Measurement Parameters: |Z| (Impedance), |Y| (Admittance), θ (Phase Angle), X (Reactance), R (Series / Parallel Resistance), G (Conductance), B (Susceptance), L (Inductance), C (Capacitance), D (Dissipation Factor), Q (Quality Factor), DCR (DC Resistance), ESR (Equivalent Series Resistance), εr (Relative Permittivity), μr (Relative Permeability)
- Measurement Modes: Meter Mode and List Mode
- Production Functions: Comparator and BIN sorting
- Accuracy Correction: Open / Short / Load correction
- Interfaces: LAN, USB Host, USB Device, RS-232, Handler
- Automation: Compatible with PLC systems and automated test equipment
MICROTEST 6632 Series Impedance Analyzer
Microtest 6632 / 6632S Impedance Analyzer is a precision impedance measurement instrument designed for advanced electrical characterization of electronic components and materials. The analyzer supports a wide measurement frequency range from 10 Hz to 1 MHz, providing accurate impedance analysis for capacitors, inductors, resistors, magnetic materials, and electronic components.
-
- Frequency Range: 10 Hz – 1 MHz
- Basic Accuracy: Up to ±0.05%
- Measurement Speed: Fast measurement for laboratory and automated testing
- Measurement Parameters: |Z|, |Y|, θ, X, R (Series / Parallel), G, B, L, C, D, Q, DCR
- Measurement Modes: Meter Mode and automated testing modes
- Display: Multi-parameter measurement display
- 6632S Features: Enhanced analysis functions, extended testing capabilities and improved automation integration
- Interfaces: LAN, USB Host, USB Device, RS-232, Handler
- Automation: Suitable for PLC integration and automated impedance measurement systems
UNI-T UT622A Professional LCR Meter
- Test Frequency: Up to 100kHz
- Measurement Accuracy: Up to 0.1%
- Display: 2.8-inch TFT LCD
- Battery: Rechargeable
- Tolerance range: 1%~20%
- Open/Short circuit clear function
- Data hold and recording mode
- Standard Mini-USB interface, SCPI command set
UNI-T UT622C Professional LCR Meter
- Up to 100kHz test frequency
- Up to 0.1% measurement accuracy
- Max reading of primary parameters:99999 counts; D/Q resolution: 0.0001
- Maximum test speed: 20 times/s (UT622E)
- Tolerance range: 1%~20%
- Open/Short circuit clear function
- Data hold and recording mode
- Standard Mini-USB interface, SCPI command set
UNI-T UTR2830E Benchtop LCR Meter (20Hz~200kHz; 1V)
- Display: 4.3-inch TFT LCD
- Frequency Range: 20Hz~200kHz
- Accuracy: ±0.02%
- Measurement Parameters: L, C, R, |Z|, D, Q, |Y|, G, X, θd, θr, RDC, Vm, Im, △%
- Interface: RS232, HANDLER, USB HOST, USB DEVICE, LAN
